1、 Scheme introduction

Automatic bonding machine is used for pressure-sensitive bonding between different materials such as LCD and touch screen.

2、 Scheme configuration

The equipment adopts Huichuan PLC-H3u+IS620 servo control, the high-definition CCD automatic alignment system feeds back the position data to the PLC, and the PLC realizes the position calibration of the servo motor through logical calculation. After the position confirmation is completed, it is sent into the high-fidelity cavity to realize vacuum fitting.

3、 Program features

1. CANlink bus mode replaces the traditional pulse control, and its simple operation improves the anti-interference and positioning accuracy of the system;

2. The standard Ethernet interface of PLC enables fast interaction with big data of vision system;

3. The program storage capacity of PLC 64K and high-speed program scanning processing are applied to various process requirements;

4. Fast fitting speed, convenient adjustment, stable operation and accurate accuracy.

4、 Product advantages

1. Now the position control of the servo can be realized through a CANDRVA command guide, and the command automatically completes the coordination of various servo states;

2. The H3U host is equipped with a 100M Ethernet communication interface, which can communicate with the vision more quickly, thus improving the operation efficiency of the whole machine.

3. Through simple Ethernet configuration, it can realize free communication with the vision system and facilitate user programming.

5、 Scheme summary

1. The CANlink bus scheme of Huichuan H3U is applied to reduce the system IO configuration and system cost;

2. Simple operation, convenient for factory technicians to maintain equipment and employees to operate and use equipment;

3. The alignment is convenient and accurate, and the product yield is high. It overcomes the defects of high frequency of bubbles, wrinkles, halo rings, water marks, offset, fragments and so on.
